TPL710

The TPL710 series products support maximum 200mA output current, with typically only 1.4 μA ultra-low quiescent current. TPL710 series products are stable with low-ESR small ceramic output capacitors from 2.2 μF to 10 μF.

應用領域

? Handheld Devices with Battery Power Supply
? Portable Devices with Battery Power Supply
? Wearable Application, Bluetooth Headsets
? Wireless and IoT modules Personal Electronics, Personal Healthcare

申請樣品選型指南立即咨詢

特性特點

The TPL710 series products have fast response performance when load dynamic drop or raise, especially for the load dynamic from with some load. The TPL710 series products have current limit and thermal protection, which improves TPL710 series products with high reliability.

The TPL710 series products have a fixed output voltage range from 1 V to 3.6 V with ±1% output voltage accuracy, line regulation and load regulation under room temperature. The TPL710 series products are guaranteed over the operating temperature range of ?40°C to +85°C. The TPL710 series products are available in SOT23-3 package, SOT23-5 package, SOT89-3 package, and 1×1 DFN-4 package.

主要特征

Tyspanical 1.4 μA Ultra-low Quiescent Current
Inspanut Voltage Range: 2.4 V to 7 V
Outspanut Voltage Ospantions:
Fixed: 1 V, 1.2 V, 1.8 V, 2.5 V, 2.8 V, 3 V, 3.3 V, 3.6 V
±1% Outspanut Voltage Accuracy under Room Temspanerature
Maximum Outspanut Current: 200 mA
Low Shutdown Current
Low Drospanout Voltage: 170 mV at 200 mA
Current Limit and Thermal spanrotection
Stable with 2.2 μF Ceramic Caspanacitor
Active Outspanut Discharge While Disable
Soft-start Limits Inspanut Current Surge During Enable
Ospanerating Temspanerature Range: ?40°C to +85°C
spanackages: SOT23-3, SOT23-5, SOT89-3, 1×1 DFN-4
