TPM8837C

The TPM8837C is a high-voltage H-bridge driver. It is designed to control inductive loads such as DC motors, solenoids and relays. It can provide up-to 1-A drive current with maximum 17-V power supply.

應用領域

? Surveillance Cameras
? E-Lock
? Consumer devices
? Toys

特性特點

The TPM8837C is a high-voltage H-bridge driver. It is designed to control inductive loads such as DC motors, solenoids and relays. It can provide up-to 1-A drive current with maximum 17-V power supply.

The TPM8837C features a solution for motors used widely in consumer products, toys and other low-to-mid voltage or battery-powered motion control applications. The output driver is an H-bridge with VM voltage ranges from 2.5 V to 17 V.Control logic can operate on 1.8-V, 3.3-V and 5-V rails.

Internal protection features such as over current protection,short circuit protection under voltage lockout and over temperature improve reliability of the whole system.

主要特征

  • 17-V H-bridge Driver
    MOSFET On-resistance Rds(on) HS + LS 0.85 Ω
    1-A Max Output Current
    Supports 2.5-V to 17-V Operating Supply Voltage
    Supports 1.8-V, 3.3-V, 5-V Logic Voltage
    PWM (IN1/IN2) interface
  • Protection

    - Under voltage Lockout Protection (UVLO)

    - Over-Current Protection (OCP)

    - Thermal Shutdown (TSD)

    Small Package Footprint

    - DFN-8 Package

樣品申請

瑞凡為用戶提供了申請單片機樣片的服務，以滿足您的研究、原型設計和測試需要
